Specifications:

• Product Number: AEROLUX-750-80BRONZE
• Total power: 750 W
• AC input voltage: 220 - 240 V
• AC input frequency: 50/60 Hz
• Input current: 5 A
• Power factor: 0.9
• Power Factor Correction (PFC) type: Active
• Combined power ( 3.3V): 120 W
• Combined power ( 12V): 696 W
• Combined power ( 5V): 120 W
• Combined power (-12V): 3.6 W
• Combined power ( 5Vsb): 12.5 W
• Max output current ( 3.3V): 20 A
• Max output current ( 12V): 58 A
• Max output current (-12V): 0.3 A
• Efficiency: 88%

Ports & interfaces

• Motherboard power connector: 20 4 pin ATX
• Motherboard power cable length: 50 cm
• Number of SATA power connectors: 5
• Number of PATA power connectors: 3
• SATA power cable length:
• 550
• 700
• 850
• PCI Express power connectors (6 2 pin): 1
• PCI Express power cable length: 45 cm
• CPU power connector (4 4 pin): Yes
• CPU power cable length: 55 cm
• ATX power connector (20 4 pin): Yes
• PCI Express connector: Yes

Performance

• 80 PLUS certification: 80 PLUS Bronze
• Purpose: PC
• Power supply unit (PSU) form factor: ATX
• ATX version: 2.4

Design

• Product colour: Black
• Cooling type: Active
• Fan diameter: 12 cm
• Number of fans: 1 fan(s)

Packaging data

• Cables included: AC

Other features

• Manual: Yes
