• Product Number: 90YE00N0-B0NA00

• Intel Form Factor: SFX-L
• PFC Type: Active PFC
• ATX 3.0: Yes
• Dimensions: 125 x 125 x 63.5 mm
• Efficiency: 80Plus Titanium
• Protection Features: OPP/OVP/UVP/SCP/OCP/OTP
• Hazardous Materials: ROHS
• AC Input Range: 100-240Vac
• DC Output Voltage: 3.3V 5V 12V -12V 5Vsb
• Maximum Load: 20A 20A 100A 0.8A 3A
• Combined Load: 110W 110W 1200W 9.6W 15W
• Total Output: 1200W

Cable Connectors

• MB 24/20-pin x 1
• CPU 4 4-pin x 2
• PCI-E 16-pin x 2 (both PSU component side)
• PCI-E 8-pin x 4
• SATA x 6
• PERIPHERAL x 4

Package Contents

• Power Cord x 1
• Motherboard Power Cable x 1 (450mm)
• CPU Cable x 2 (550mm)
• PCI-E Gen 5 16-pin Cable x 2 (450mm)
• PCI-E (16-pin to 8-pin-8-pin) Cable x 2 (450mm)
• SATA 1-to-3 Cable x 2 (300 200 100mm)
• Peripheral 1-to-4 Cable x 1 (300 100 100 100mm)
• Addressable RGB Cable x 1 (800mm)
• User Manual x 1
• ATX to SFX adapter bracket x 1
• Weight: 2.15 kg (single PSU)
• AURA SYNC: ARGB
• Cybenetics Noise Level Certification: S
