Specifications:

• Product Number: 90YE00N4-B0NA00


Power

• Total power: 750 W
• AC input voltage: 100 - 240 V
• Combined power ( 3.3V): 110 W
• Combined power ( 12V): 750 W
• Combined power ( 5V): 110 W
• Combined power (-12V): 9.6 W
• Combined power ( 5Vsb): 12.5 W
• Max output current ( 3.3V): 20 A
• Max output current ( 12V): 62.5 A
• Max output current ( 5V): 20 A
• Max output current (-12V): 0.8 A
• Max output current ( 5Vsb): 2.5 A

Ports & interfaces

• Motherboard power connector: 20 4 pin ATX
• Number of SATA power connectors: 6
• Peripheral (Molex) power connectors: (4-pin) 4
• PCI Express power connectors (8-pin): 3
• PCI Express power connectors (16-pin): 1
• CPU power connector (4 4 pin): Yes

Performance

• 80 PLUS certification: 80 PLUS Platinum
• Supported motherboard form factors: ATX
• Purpose: PC
• Power supply unit (PSU) form factor: SFX
• Silent mode: Yes
• Certification: OPP/OVP/UVP/SCP/OCP/OTP

Design

• Product colour
• Black
• Silver
• Fan diameter: 12 cm
• Number of fans: 1 fan(s)
• Illumination: Yes

Weight & dimensions

• Width: 125 mm
• Depth: 125 mm
• Height: 63.5 mm
• Weight: 1.81 kg

Technical details

• Sustainability certificates: RoHS
