PFC Type

Active PFC

Dimensions

16 x 15 x 8.6 Centimeter

Efficiency

80Plus Gold

Protection Features

OPP/OVP/UVP/SCP/OCP/OTP

Hazardous Materials

ROHS

AC Input Range

100-240Vac

Thermal Features

ROG Thermal Solution

DC Output Voltage

3.3V 5V 12V -12V 5Vsb

Maximum Load

25A 25A 83A 0.3A 3A

Combined Load

125W 996W 3.6W 15W

Total Output

1000W

Cable Connectors

MB 24/20-pin x 1

CPU 4 4-pin x 2

PCI-E 6 2-pin x 6

SATA x 8

PERIPHERAL x 6

Package Contents

Power Cord x 1

Motherboard Power Cable x 1 (610mm)

CPU Cable x2 (1000mm)

PCIE 1-to-2 Cable x3 (675 75mm)

SATA 1-to-4 Cable x1 (410 150 150 150mm)

SATA 1-to-4 Cable x1 (450 120 120 120mm)

Peripheral 1-to-3 Cable x2 (450 120 120mm)

ROG badge x 2

ROG logo magnet x 1

ROG label x 3

*MB/ CPU/ PCI-E cables come with embedded capacitors in the middle.

Weight

1.885 Kg

Cybenetics Noise Level Certification

NA

0dB Technology

Supported. The fan shuts off entirely when the PSU is under certain load
