Specifications:

• Product Number: BN320
• Model: SFX Power 3 300W
• Continuous power (W): 300
• Peak power (W): 350
• Form factor: SFX12V Version 3.42
• Form factor EPS 12V: Version 2.92
• Topology: DC/DC
• Digitally controlled: -
• Voltage (Vac): 100 - 240
• Frequency (Hz): 50 - 60
• Input current (A): 5 / 2
• Power factor at 100% load: >0.98
• Modern standby: ✓
• Power consumption in standby (W): <0.11
• Average life time (h / 25°C): 100,000
• Operating temperature up to (°C): 40

Fan and cooling technology

• Fan: High quality fan

• Fan size (mm): 80

• Bearing technology: Rifle

• Motor technology: 4-pole fan motor

• Max. fan speed (rpm): 1979

• dB(A) at 10% load: 14.4

• dB(A) at 20% load: 14.4

• dB(A) at 50% load: 14.4

• dB(A) at 100% load: 29.4

Cables and connectors

• Modular cables: -

• Sleeved cables: P24

• Flat cables: P4, PCIe, drives

• Maximum cable length (cm): 60

• Cable length to motherboard (cm): 35

• No. of cables: 5

• ATX-Motherboard (20 4-pin): 1

• P4 4 (CPU): -

• P8 (CPU): -

• P4 (CPU): 1

• 12VHPWR cables: 0

• PCI-e 6 2-pin (GPU): 1

• PCI-e 6-pin (GPU): -

• SATA: 3

• PATA: 2

• FDD (Floppy): 1

Dimensions

• Dimensions, package (L x W x H), (mm): 75 x 197 x 207

• Gross weight, package (kg): 1.2

• Pieces per packaging unit: 6

• Dimensions, shipping box (L x W x H), (mm): 457 x 265 x 233

• Gross weight, shipping box (kg): 7.9
