Brand New XPG PYLON - 550 Watts 80 Bronze/Single Rail 12v Non-Modular 120mm FDB Silent-Performance Fan, Multiple PCI-E 2.0 6 2 Pin Connectors High-end Reliable, Intelligent, Power Supply PY1818 1ION

Product Specifications

• DC to DC Converters
• 80PLUS BRONZE Certified
• Continuous Power for 24/7 system operation
• 120mm FDB Silent-Performance Fan
• High Current 12V rail system compatibility
• Main Japanese Capacitor
• Multiple PCI-E 2.0 6 2 Pin Connectors
• Industrial-Level Protection OVP, OPP, SCP, OCP, UVP, OTP, NLO, SIP
• Complies with ErP 2014 Lot 3
• RoHS Compliance
• Dimensions (L x W x H): 150 x 140 x 86mm
• 80 PLUS RATING: BRONZE:
• ATX Version: Intel ATX 12V V2.4 (Timing complies with Intel ATX12V Specific guidelines to version 2.52)
• Protections: OCP / OVP / UVP / OPP / SCP / OTP / NLO / SIP
• Certification: CE / UKCA / CB / FCC (IC) / EAC / CCC / TUV / cTUVus / TUV S-Mark / RCM / NOM / BSMI / KC
• PFC: 0.99
• Input Voltage: 100-240V
• Input Current: 750W：10A/5A 、650W：10A/5A 、550W：8A/4A 、450W：7A/3.5A
• Input Frequency: 50Hz - 60Hz
• Operating Temperature: 50℃
• Fan Size: 120mm
• Fan Bearing: FDB (Fluid Dynamic Bearing)
• Fan Speed: 2,000 RPM
• Noise Level: NA
• MTBF: 100K Hours at 25℃
• ATX 24 Pin Connector: 1
• EPS 8 (4 4) Pin Connector: 550W : 1
• SATA Connector: 750W : 550W : 5
• Peripheral 4 Pin Connector: 550W : 1
• PCI-E 6 2 Pin Connector: 550W : 2
