Unlock the analog potential of MiSTer FPGA with IO Direct! Boasting accurate analog video, crystal clear analog audio, soft power toggle, and compatibility with the incredible .*

* Requires a new rear panel

Features

• Reference-quality analog video and audio via Sega Saturn AV port
• 99% accurate to specifications
• RGB
• YPbPr with improved sync levels
• S-Video (native YC support)
• Composite Video (native YC support)
• 24-bit video depth
• Hi-Fi analog audio
• Mini TOSLINK digital audio
• USB-C power with soft power toggle
• ADC-In (integrated into the rear 3.5mm port)
• User port for SNAC and mt32-pi
• Analog video OR HDMI output
• Dual SDRAM support
• Looking for a single SDRAM IO board, for that sweet simultaneous HDMI and analog audio and video? Check out ! No cores currently require dual SDRAM. Jaguar (alpha), Saturn (beta), and Williams Y/Z unit arcade machines (upcoming) all need or benefit dual SDRAM.

Included Accessories

• HDMI Jumper
• 40mm fan (optional)
• 20mm heatsink (optional)

Recommended Accessories

•  (running low on some colors - consider black and a as an alternative until I can make more).

Configuration

Please refer to the MiSTer.ini section of the

Video measurements

Note: All non-MiSTer Addons measurements were taken by .
