Specifications

PCIe standard
PCIe Gen 4.0 x 16

Front IO ports
1 x USB 3.1 Type-C, 2 x USB 3.0

Rear IO ports
Power button

Tool-less push-to-lock
Both side, top, and front panels

Top and front panel
Fine mesh panels

Side panel
Fine mesh panels

Expansion slots
Vertical GPU: up to 4 slots; horizontal GPU: 3 slots

2.5" drive mounts
Vertical GPU: 3 x 2.5” SSD; horizontal SFF GPU: 6 x 2.5” SSD

3.5" drive mounts
Vertical GPU: 1 x 3.5” HDD; horizontal SFF GPU: 3 x 3.5” HDD

Front fan mounts
2 x 120/140 mm (not included)

Top fan mounts
1 x 120 mm x 15 mm thick

Right side fan mounts
2 x 120/140 mm fans with 2.5 slot GPU in 4 slots GPU mode

Compatibility

Motherboard compatibility
Mini-ITX; Mini-DTX, MATX, ATX (extra PCIe card needed)

Power supply type
SFX, SFX-L, ATX

Power supply max length
170 mm ATX PSU with front fan;
150 mm ATX PSU with front AIO

CPU cooler max height
3 slots GPU: max 74 mm height
4 slots GPU: max 54 mm height

GPU max length ITX MB
332 mm length and 152 mm width; 343 mm length and 152 mm width with extra feet

GPU max length ATX MB
314 mm length and 120 mm width; 325 mm length and 120 mm width with extra feet

Front radiator ITX MB
240/280 mm (max 332 mm length, 144 mm wide, 63 mm thick with fans)

Right side radiator ITX MB
4 slots GPU mode: 45 mm thick of 240/280 mm radiator fans allow GPU in 32 mm thick

Right side radiator ATX MB
3 slots GPU mode: 240 mm support max 120 mm wide, 53 mm thick with fans

General

Case dimensions
247 x 167 x 362 mm / 9.72 x 6.57 x 14.25 inch

Package dimensions
415 x 220 x 310 mm / 16.34 x 8.66 x 12.2 inch

Case material
SGCC powder coated steel, plastic

Net weight
2.95 kg / 6.5 lb

Gross weight
3.5 kg / 7.72 lb

Volume
14.93 liters

Package contents
Case, accessory box

Warranty
2 years
